Crane truck Scania R480 10x4 with Palfinger PK44002 with jib and hooklift

• Steering axle

Transmission type : Automatic

Crane make : Palfinger

Crane type : PK 44002 with jib

Crane year : 2007

Crane position : Behind the cabin

SCANIA R480 5-axle Hokkloader with Palfinger crane and jib

The truck was on display until 2010 and is therefore not in use until then

Equipment:

- Model year 2007, bu in use first time 2010

- Euro 4

- Odometer reading approx. 510,000 km but is still in production

- Last approved inspection 2024-09-18

- Inspection latest 2025-07-31

- Tachograph inspected 2023-09-01

- Crane newly inspected upon delivery

- Opticruise automatic, with clutch pedal

- Retarder

- Parabolic suspension axle 1+2 air suspension rear

- Steerable axle 1+2 and trailing axle

- Very good tires, see spec

- Sleeper cab, Highline

- Extra lights on roof arch and in sun visor

- Reversing lights led

- Leather upholstery

- Rear view camera

- Leather-covered steering wheel with steering wheel buttons

- Cruise control

- Load indicator

- Radio

- Refrigerator

- AC, mm

- Joab L24, -24 ton demountable truck

- External hydraulic flatbed locks

- Rear tipper hydraulics

- Air-controlled drawbar

- Crane Palfinger PK 44002

- 7 hydraulic extensions in the base crane

- 18.2 meter hydraulic reach in the base crane according to the nameplate

- Hose and pipe set

- Jib Palfinger PJ060 with 2 extensions

- Total reach according to the nameplate approx. 24.9 meters

- Hydraulic support legs, front and rear

- Remote control with dual batteries and charger

- Start and stop of the engine and rpm etc. from the remote control

- Crane hours approx. 8827 hours

Service:

According to plan

Repairs:

New egr

Clutch replaced 2023

Length 10150 mm

Width 2550 mm

Height Information missing.

Operating weight (actual weight) 22245 kg

Maximum load weight 23755 kg

Total weight 46000 kg

Original total weight 46000 kg

Tax weight 32000 kg

Permissible load weight 9755 kg

Rear overhang 1550 mm

Axle - 1 Max axle distance axle 1-2 1940 mm

Guaranteed axle/bogie pressure 18000 kg

Axle - 2 Max axle distance axle 2-3 2360 mm

Axle - 3 Max axle distance axle 3-4 1360 mm

Guaranteed axle/bogie pressure 28000 kg

Axle - 4 Max axle distance axle 4-5 1310 mm

Maximum trailer weight 33450 kg

Maximum trailer weight 21780 kg

Maximum combined gross weight (train weight) 90000 kg

Coupling distance 9800 mm Read full description
